About Description Smooth and Powerful XING2 Motors The latest upgrade of our bestseller XING motors, no compromises taken! Durable unibell (one-piece bell) technology, strong titanium alloy shaft with reinforced bell joint, crash resistant 7075 aluminum bell, smooth and long-lasting Japanese NSK bearings, center slotted N52H curved arc magnets and our XING O-ring bushing gap protection. Latest Nazgul Frame for Maximum Protection The old days are over, getting your electronics full of dirt and wet grass every time you crash. Our latest frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts. DJI O3 HD Air Unit Low-Latency digital transmission Up to 10 km video transmission range, enjoy a crisp and smooth real-time view in your goggles, even in environments with interference. (Source DJI) 4K Stabilized Video with 155° Ultra-Wide Angle Together with high-grade imaging performance, it delivers exceptional visuals that will keep your audience on the edge of their seats. (Source DJI) Secured Battery Plug with Anti-Spark Filter Plugging in a battery can create a loud spark at the connector which is caused by the high battery current rushing into the low ESR capacitor first as well as filling up ESC capacitance. We’ve added a protective circuit to extend the lifespan of XT60 connectors and prevent rapid voltage or current spikes which can protect your electronics from damage. Specially Designed Heatsink for DJI O3 HD Air Unit Improved cooling performance for the high power draw of the DJI O3 video transmitter. We’ve added a custom CNC heatsink for excellent heat dissipation without overheating, even on high power levels. Specifications: Product Name: Evoque F6 V2 FC: BLITZ Mini F722 Flight Controller ESC: BLITZ Mini E55 4-IN-1 2-6S 55A ESC Video Transmission: DJI O3 Air Unit Frame wheelbase: 255mm (Squashed X) / 262 mm (DeadCat) Motor: XING2 2506 1500KV motors Prop: 6 inch propellers Weight: 480/485 grams Takeoff Weight: Approx. 680 g Dimensions (L×W×H): 196×164×36±2mm (Squashed X) / 209×162×36±2mm (DeadCat) Diagonal Distance: 120 mm Max Speed: 180 Km/H (Manual Mode) Maximum Takeoff Altitude: 3200 m Max Hover Time: Approx. 8 mins (With 1400mAh battery) Max Flight Distance: 5 km Max Wind Speed Resistance: Level 57 Operating Temperature Range：-10° to 40° C (14° to 104° F) Antennas: Dual Antennas GNSS: GPS+SBAS+Galileo+QZSS+Glonass Video Transmission: Product Name: DJI O3 Air Unit Weight: Approx. 36.4 grams（headband included） Communication Bandwidth： Max 40 MHz FOV (single screen): 155° Communication Frequency：2.400-2.4835 GHz (RX only) / 5.725-5.850 GHz (RX and TX) End-to-End Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms. Max Video Transmission Bitrate: 50 Mbps Max Video Transmission Range：10 km (FCC), 2 km (CE), 6 km (SRRC) Operating Temperature Range: -10º to 40º C (14° to 104° F) Power Input: 7.4-26.4 V Audio Transmission: N/A Packing List: 1 x Evoque F6 6S HD BNF 2 x Antennas 1 x Battery pad 2 x propeller(Pairs) 2 x Battery strap Notice: All iFlight BNFs are tested before shipment to guarantee highest quality.If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Characteristics Size 6 inch Geometry Squashed X or DeadCat Flight Stack BLITZ Mini F7/E55 Motors 2506 1500KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS Module M10 chipset Max. Speed 180 km/h Weight ca. 480 (without battery) Description Smooth and Powerful XING2 Motors The latest upgrade of our bestseller XING motors, no compromises taken! Durable unibell (one-piece bell) technology, strong titanium alloy shaft with reinforced bell joint, crash resistant 7075 aluminum bell, smooth and long-lasting Japanese NSK bearings, center slotted N52H curved arc magnets and our XING O-ring bushing gap protection. Latest Nazgul Frame for Maximum Protection The old days are over, getting your electronics full of dirt and wet grass every time you crash. Our latest frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts. DJI O3 HD Air Unit Low-Latency digital transmission Up to 10 km video transmission range, enjoy a crisp and smooth real-time view in your goggles, even in environments with interference. (Source DJI) 4K Stabilized Video with 155° Ultra-Wide Angle Together with high-grade imaging performance, it delivers exceptional visuals that will keep your audience on the edge of their seats. (Source DJI) Secured Battery Plug with Anti-Spark Filter Plugging in a battery can create a loud spark at the connector which is caused by the high battery current rushing into the low ESR capacitor first as well as filling up ESC capacitance. We’ve added a protective circuit to extend the lifespan of XT60 connectors and prevent rapid voltage or current spikes which can protect your electronics from damage. Specially Designed Heatsink for DJI O3 HD Air Unit Improved cooling performance for the high power draw of the DJI O3 video transmitter. We’ve added a custom CNC heatsink for excellent heat dissipation without overheating, even on high power levels. Specifications: Product Name: Evoque F6 V2 FC: BLITZ Mini F722 Flight Controller ESC: BLITZ Mini E55 4-IN-1 2-6S 55A ESC Video Transmission: DJI O3 Air Unit Frame wheelbase: 255mm (Squashed X) / 262 mm (DeadCat) Motor: XING2 2506 1500KV motors Prop: 6 inch propellers Weight: 480/485 grams Takeoff Weight: Approx. 680 g Dimensions (L×W×H): 196×164×36±2mm (Squashed X) / 209×162×36±2mm (DeadCat) Diagonal Distance: 120 mm Max Speed: 180 Km/H (Manual Mode) Maximum Takeoff Altitude: 3200 m Max Hover Time: Approx. 8 mins (With 1400mAh battery) Max Flight Distance: 5 km Max Wind Speed Resistance: Level 57 Operating Temperature Range：-10° to 40° C (14° to 104° F) Antennas: Dual Antennas GNSS: GPS+SBAS+Galileo+QZSS+Glonass Video Transmission: Product Name: DJI O3 Air Unit Weight: Approx. 36.4 grams（headband included） Communication Bandwidth： Max 40 MHz FOV (single screen): 155° Communication Frequency：2.400-2.4835 GHz (RX only) / 5.725-5.850 GHz (RX and TX) End-to-End Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms. Max Video Transmission Bitrate: 50 Mbps Max Video Transmission Range：10 km (FCC), 2 km (CE), 6 km (SRRC) Operating Temperature Range: -10º to 40º C (14° to 104° F) Power Input: 7.4-26.4 V Audio Transmission: N/A Packing List: 1 x Evoque F6 6S HD BNF 2 x Antennas 1 x Battery pad 2 x propeller(Pairs) 2 x Battery strap Notice: All iFlight BNFs are tested before shipment to guarantee highest quality.If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Characteristics Size 6 inch Geometry Squashed X or DeadCat Flight Stack BLITZ Mini F7/E55 Motors 2506 1500KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS Module M10 chipset Max. Speed 180 km/h Weight ca. 480 (without battery) -
About Description Remarkably Lightweight And Portable The palm-sized, compact Defender 20 is just as portable as it can be. The whole frame is injection molded for durability and lightweight, equipped with a naked DJI O3 air unit (Supplied by DJI). It's not only regulation-friendly, but also the safest in its series, allowing you to fly anywhere and whenever. One-button Functional Power Switch Better operation through one physical button, not only just power on and off but also inbuilt programmable RGB light colors and modes to visually display the battery power. We’ve added a protective circuit to extend the lifespan of the battery connector and prevent rapid voltage or current spikes which can protect your electronics from damage. Innovative Quick-Release Battery with Type-C Charger The Defender 20 comes with a stock 3S 900mAh providing up to 7min flight time. Crash protected battery shell and innovative quick-release structure for easy replacement. Upgraded plug and play Type-C charger for user-friendly fast charging, get 80% charge in just 18 minutes. The battery has an inbuilt auto-discharge module, it will discharge itself when not in use, making it safe and worry-free. Extremely Convenient User Experience No fear of dust, take off boldly. By using dustproof port plugs to isolate the interface from the outside, ensure function properly. Extend the life of the interface. The drone can be disassembled with only 6 screws, making it much more convenient for maintenance and repair. Full plug and play high performance AIO, 30% increase in redundancy to cope with extreme operations. Integrated beeper for quick retrieval of accidental loss. All ports and buttons are easy to access. Countless easy-to-use features let you get started right away. 1) No soldering is required for the whole drone, motors, and propellers adopting the plug-in mounting method. 2) A dedicated VTX mount bracket with a central grille opening, together with the air duct design in the drone, can dissipate heat when flying. 3) USER1 preset as video transmitter power supply switch, used to manually turn off the VTX when idle to safe power and prevent overheating. 4) Customized vibration damped O3 camera mount to keep your raw footage as smooth as possible, as well as ensure good Gyro Data for the in-built or in-post camera stabilization, jello free. Specifications: Product Name: Defender 20 O3 3S HD Flight Electronics: Defender 16/20 F411 AIO Video Transmission: DJI O3 Air Unit (Naked version) Frame wheelbase: 97mm Motor: Defender20 1204 motors Prop: Defender20 2020-3 props Takeoff Weight incl. 900mAh battery: 178g Dimensions (L×W×H)：135x136x52mm Max Speed: 75Km/H (Manual Mode) Maximum Takeoff Altitude: 2000 m Max Hover Time: Approx. 7.5 mins(with 3S 900mAh battery) Max Wind Speed Resistance: Level 3 Operating Temperature Range: -10° to 40° C (14° to 104° F) Antennas: Dual Antennas GNSS: N/A Video Transmission: Product Name: Naked DJI O3 Air Unit Communication Bandwidth: Max 40 MHz FOV (single screen): 155° Communication Frequency: 2.400-2.4835 GHz (RX only)；5.725-5.850 GHz(RX and TX) End-to-End Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms. Max Video Transmission Bitrate: 50 Mbps Max Video Transmission Range：10 km (FCC), 2 km (CE), 6 km (SRRC) Operating Temperature Range: -10º to 40º C (14° to 104° F) Power Input: 7.4-26.4 V Audio Transmission: N/A Packing List: 1 x Defender 20 O3 HD BNF 1 x Defender 20 3S 900mAh Battery 1 x Charging Adapter 4 x Defender 2020-3 Props (pairs) 1 x Propeller Removal Tool 1 x Defender 20 Carrying Case Notice: All iFlight BNFs are tested before shipment to guarantee highest quality. If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Characteristics Size 2 inch Geometry Ducted Flight Stack Defender 16/20 F411 AIO Motors 1204 6200KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS Module No Max. Speed 75 km/h Take Of Mass incl. 900mAh battery: 178g Description Remarkably Lightweight And Portable The palm-sized, compact Defender 20 is just as portable as it can be. The whole frame is injection molded for durability and lightweight, equipped with a naked DJI O3 air unit (Supplied by DJI). It's not only regulation-friendly, but also the safest in its series, allowing you to fly anywhere and whenever. One-button Functional Power Switch Better operation through one physical button, not only just power on and off but also inbuilt programmable RGB light colors and modes to visually display the battery power. We’ve added a protective circuit to extend the lifespan of the battery connector and prevent rapid voltage or current spikes which can protect your electronics from damage. Innovative Quick-Release Battery with Type-C Charger The Defender 20 comes with a stock 3S 900mAh providing up to 7min flight time. Crash protected battery shell and innovative quick-release structure for easy replacement. Upgraded plug and play Type-C charger for user-friendly fast charging, get 80% charge in just 18 minutes. The battery has an inbuilt auto-discharge module, it will discharge itself when not in use, making it safe and worry-free. Extremely Convenient User Experience No fear of dust, take off boldly. By using dustproof port plugs to isolate the interface from the outside, ensure function properly. Extend the life of the interface. The drone can be disassembled with only 6 screws, making it much more convenient for maintenance and repair. Full plug and play high performance AIO, 30% increase in redundancy to cope with extreme operations. Integrated beeper for quick retrieval of accidental loss. All ports and buttons are easy to access. Countless easy-to-use features let you get started right away. 1) No soldering is required for the whole drone, motors, and propellers adopting the plug-in mounting method. 2) A dedicated VTX mount bracket with a central grille opening, together with the air duct design in the drone, can dissipate heat when flying. 3) USER1 preset as video transmitter power supply switch, used to manually turn off the VTX when idle to safe power and prevent overheating. 4) Customized vibration damped O3 camera mount to keep your raw footage as smooth as possible, as well as ensure good Gyro Data for the in-built or in-post camera stabilization, jello free. Specifications: Product Name: Defender 20 O3 3S HD Flight Electronics: Defender 16/20 F411 AIO Video Transmission: DJI O3 Air Unit (Naked version) Frame wheelbase: 97mm Motor: Defender20 1204 motors Prop: Defender20 2020-3 props Takeoff Weight incl. 900mAh battery: 178g Dimensions (L×W×H)：135x136x52mm Max Speed: 75Km/H (Manual Mode) Maximum Takeoff Altitude: 2000 m Max Hover Time: Approx. 7.5 mins(with 3S 900mAh battery) Max Wind Speed Resistance: Level 3 Operating Temperature Range: -10° to 40° C (14° to 104° F) Antennas: Dual Antennas GNSS: N/A Video Transmission: Product Name: Naked DJI O3 Air Unit Communication Bandwidth: Max 40 MHz FOV (single screen): 155° Communication Frequency: 2.400-2.4835 GHz (RX only)；5.725-5.850 GHz(RX and TX) End-to-End Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms. Max Video Transmission Bitrate: 50 Mbps Max Video Transmission Range：10 km (FCC), 2 km (CE), 6 km (SRRC) Operating Temperature Range: -10º to 40º C (14° to 104° F) Power Input: 7.4-26.4 V Audio Transmission: N/A Packing List: 1 x Defender 20 O3 HD BNF 1 x Defender 20 3S 900mAh Battery 1 x Charging Adapter 4 x Defender 2020-3 Props (pairs) 1 x Propeller Removal Tool 1 x Defender 20 Carrying Case Notice: All iFlight BNFs are tested before shipment to guarantee highest quality. If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Characteristics Size 2 inch Geometry Ducted Flight Stack Defender 16/20 F411 AIO Motors 1204 6200KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS Module No Max. Speed 75 km/h Take Of Mass incl. 900mAh battery: 178g -
About Description Our latest BLITZ Mini Flight Controller used in our iFlight BNFs. Ultra fast F7 MCU for 2-6S batteries. 20x20 mounting pattern. The perfect match for your new frame. Improved circuit design, better components and lower electrical noise! DJI HD VTX Connector (Plug-and-Play / No soldering required), FC indicator LEDs for visual debugging, with LC filter. Specifications: MCU: STM32 F722 Gyro: ICM42688 Barometer: DPS310 OSD Chip: AT7456 Flash: 8MB (Blackbox flash) UARTS: 6 Motor outputs: 4x (SH1.0 connector) I2C serial: SDA/SLA pads Smartaudio / IRC Tramp VTX protocol supported LED controller: Yes Beeper pad: Yes Firmware target: IFRC-IFLIGHT_BLITZ_F722 Mount pattern: 20x20 mm / 4mm PCB hole diameter, silicon grommets for M3 screws Dimensions: 30.5x27 mm Weight: 5g Wiring Suggestions: UART 1 for VTX HD / Analog UART 2 for a Receiver UART 3/4/5 for GPS or other sensors that require a serial port UART 6 for ESC Telemetry Wiring Diagram: https://drive.google.com/drive/u/1/folders/17Uf67I6ER_z-otviR0I7tSqO31W7S553 Packing List: 1 x BLITZ Mini F7 V1.2 Flight Controller 1 x FC connectors 1 x Silicon grommets Description Our latest BLITZ Mini Flight Controller used in our iFlight BNFs. Ultra fast F7 MCU for 2-6S batteries. 20x20 mounting pattern. The perfect match for your new frame. Improved circuit design, better components and lower electrical noise! DJI HD VTX Connector (Plug-and-Play / No soldering required), FC indicator LEDs for visual debugging, with LC filter. Specifications: MCU: STM32 F722 Gyro: ICM42688 Barometer: DPS310 OSD Chip: AT7456 Flash: 8MB (Blackbox flash) UARTS: 6 Motor outputs: 4x (SH1.0 connector) I2C serial: SDA/SLA pads Smartaudio / IRC Tramp VTX protocol supported LED controller: Yes Beeper pad: Yes Firmware target: IFRC-IFLIGHT_BLITZ_F722 Mount pattern: 20x20 mm / 4mm PCB hole diameter, silicon grommets for M3 screws Dimensions: 30.5x27 mm Weight: 5g Wiring Suggestions: UART 1 for VTX HD / Analog UART 2 for a Receiver UART 3/4/5 for GPS or other sensors that require a serial port UART 6 for ESC Telemetry Wiring Diagram: https://drive.google.com/drive/u/1/folders/17Uf67I6ER_z-otviR0I7tSqO31W7S553 Packing List: 1 x BLITZ Mini F7 V1.2 Flight Controller 1 x FC connectors 1 x Silicon grommets -
About Description Highlights Stable output power 4 Power levels up to 1600mW; 40 Channels (including Raceband) Fast frequency lock, no startup interference with other pilots Built-in output power self-check functionality VTX telemetry with IRC Tramp protocol Note: VTX is set to 25mW by default! Power levels above 25mW require a HAM license or have to be approved by local authorities! Please ensure you're flying legal frequencies and use our prepared Betaflight VTX tables according to your region. iFlight BNF Compatibility: Stock VTX for Nazgul5 V3 Analog Specifications: Input voltage: 7V～34V Interface: MMCX Power levels: PIT/25mW/400mW/800mW/1600mW Channels: 40 (including Raceband) Mounting pattern: 30.5x30.5mm/Φ3 Lightweight: 18.9g (excluding antenna) VTX telemetry: IRC Tramp Betaflight IRC Tramp Configuration: Please download the attached VTX table for Betaflight! RC Tramp VTX table values: 25mW/400mW/800mW/1600mW PDF Instructions: https://drive.google.com/drive/folders/1PangELyOFYp0kknmzMPgHx7xfat-Ggve Packing List: 1x BLITZ 5.8G 1.6W VTX Description Highlights Stable output power 4 Power levels up to 1600mW; 40 Channels (including Raceband) Fast frequency lock, no startup interference with other pilots Built-in output power self-check functionality VTX telemetry with IRC Tramp protocol Note: VTX is set to 25mW by default! Power levels above 25mW require a HAM license or have to be approved by local authorities! Please ensure you're flying legal frequencies and use our prepared Betaflight VTX tables according to your region. iFlight BNF Compatibility: Stock VTX for Nazgul5 V3 Analog Specifications: Input voltage: 7V～34V Interface: MMCX Power levels: PIT/25mW/400mW/800mW/1600mW Channels: 40 (including Raceband) Mounting pattern: 30.5x30.5mm/Φ3 Lightweight: 18.9g (excluding antenna) VTX telemetry: IRC Tramp Betaflight IRC Tramp Configuration: Please download the attached VTX table for Betaflight! RC Tramp VTX table values: 25mW/400mW/800mW/1600mW PDF Instructions: https://drive.google.com/drive/folders/1PangELyOFYp0kknmzMPgHx7xfat-Ggve Packing List: 1x BLITZ 5.8G 1.6W VTX -
About Description Latest Chimera9 ECO Frame for Maximum Protection The old days are over, getting your electronics full of dirt and wet grass every time you crash. Our latest frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts. Economic and Efficient Electrical System Equipped with the BLITZ ATF435 Flight Controller, BLITZ 1.6W/2.5W Whoop VTX, and the BLITZ E55S 4-in-1 ESC, this setup offers a high level of power and functionality. Specifications: Product Name: Chimera9 ECO 6S Analog FC: BLITZ ATF435 Flight Controller ESC: BLITZ E55S 4-IN-1 2-6S 55A ESC Video Transmission: BLITZ Whoop 1.6W VTX/ BLITZ Whoop 2.5W VTX Geometry: DeadCat(DC) Frame: 405mm wheelbase Motor: XING-E 2809 800KV motors Prop: 9X4X3 propellers Weight: 721g (Without Battery) Dimensions (L×W×H): 360x235x34mm Max Speed: 140km/h Maximum Takeoff Altitude: 6000 m Max Hover Time: Approx. 33 mins (With 6S2P 8000mAh no load) Operating Temperature Range: -10° to 40° C (14° to 104° F) Antennas: Single Antennas GNSS: GPS+SBAS+Galileo+QZSS+Glonass (Optional) Payload: 1.5-2.2kg Video Transmission (optional): Product Name: BLITZ Whoop 5.8G 1.6W VTX Output Power: 0-25-400-800-1600mw Input Volts: 12V Working Current: ≤pit @40mA，≤25mw@150mA，≤400mw@330mA，≤800mw@460mA，≤1600mw@660mA Transmission fre: 40CH(A-B-E-F-R) Antenna Interface: IPEX Mounting Hole: 25*25/φ1.6mm Weight: 16.5g (Antenna not included) Dimensions: 37*31.5*10mm Product Name: BLITZ Whoop 5.8G 2.5W VTX Output Power: 0-25-400-1000-2500mw Input Volts: 7-34V Working Current: ≤pit @12V 140mA, ≤25mw@12V 200mA, ≤400mw@12V 340mA, ≤1000mw@12V 480mA, ≤2500mw@12V 780mA Transmission fre: 40CH(A-B-E-F-R) Antenna Interface: MMCX Mounting Hole: 25*25/φ1.6mm Weight: 32g Dimensions: 50*30*16mm Packing List: 1 x Chimera9 ECO 6S Analog BNF 1 x Battery pad 1 x Antenna 2 x Propellers(Pairs) 2 x Battery strap Characteristics Size 9 inch Geometry DeadCat Flight Stack BLITZ ATF/E55S Motors 2809 800KV Video Transmitter 5.8G 1.6W/2.5W (optional) Radio Transmitter PNP, ELRS, TBS (optional) GPS (optional) M10 chipset Max. Speed 140 km/h Weight ca. 721g (without battery) Description Latest Chimera9 ECO Frame for Maximum Protection The old days are over, getting your electronics full of dirt and wet grass every time you crash. Our latest frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts. Economic and Efficient Electrical System Equipped with the BLITZ ATF435 Flight Controller, BLITZ 1.6W/2.5W Whoop VTX, and the BLITZ E55S 4-in-1 ESC, this setup offers a high level of power and functionality. Specifications: Product Name: Chimera9 ECO 6S Analog FC: BLITZ ATF435 Flight Controller ESC: BLITZ E55S 4-IN-1 2-6S 55A ESC Video Transmission: BLITZ Whoop 1.6W VTX/ BLITZ Whoop 2.5W VTX Geometry: DeadCat(DC) Frame: 405mm wheelbase Motor: XING-E 2809 800KV motors Prop: 9X4X3 propellers Weight: 721g (Without Battery) Dimensions (L×W×H): 360x235x34mm Max Speed: 140km/h Maximum Takeoff Altitude: 6000 m Max Hover Time: Approx. 33 mins (With 6S2P 8000mAh no load) Operating Temperature Range: -10° to 40° C (14° to 104° F) Antennas: Single Antennas GNSS: GPS+SBAS+Galileo+QZSS+Glonass (Optional) Payload: 1.5-2.2kg Video Transmission (optional): Product Name: BLITZ Whoop 5.8G 1.6W VTX Output Power: 0-25-400-800-1600mw Input Volts: 12V Working Current: ≤pit @40mA，≤25mw@150mA，≤400mw@330mA，≤800mw@460mA，≤1600mw@660mA Transmission fre: 40CH(A-B-E-F-R) Antenna Interface: IPEX Mounting Hole: 25*25/φ1.6mm Weight: 16.5g (Antenna not included) Dimensions: 37*31.5*10mm Product Name: BLITZ Whoop 5.8G 2.5W VTX Output Power: 0-25-400-1000-2500mw Input Volts: 7-34V Working Current: ≤pit @12V 140mA, ≤25mw@12V 200mA, ≤400mw@12V 340mA, ≤1000mw@12V 480mA, ≤2500mw@12V 780mA Transmission fre: 40CH(A-B-E-F-R) Antenna Interface: MMCX Mounting Hole: 25*25/φ1.6mm Weight: 32g Dimensions: 50*30*16mm Packing List: 1 x Chimera9 ECO 6S Analog BNF 1 x Battery pad 1 x Antenna 2 x Propellers(Pairs) 2 x Battery strap Characteristics Size 9 inch Geometry DeadCat Flight Stack BLITZ ATF/E55S Motors 2809 800KV Video Transmitter 5.8G 1.6W/2.5W (optional) Radio Transmitter PNP, ELRS, TBS (optional) GPS (optional) M10 chipset Max. Speed 140 km/h Weight ca. 721g (without battery) -
About Description Our latest BLITZ Stack used in our iFlight BNFs. Ultra fast AT32F435 MCU, powerful 55A for 2-6S batteries. 20x20 mounting pattern. The perfect match for your new frame. Improved circuit design, better components and lower electrical noise! DJI HD VTX Connector (Plug-and-Play / No soldering required), FC indicator LEDs for visual debugging, with LC filter. FC Specifications: MCU: AT32F435RGT7 Gyro: BMI270 Barometer: DPS310 OSD Chip: AT7456E Flash: 16MB (Blackbox flash) UARTS: 6 Motor outputs: 4x (SH1.0 connector) I2C serial: SDA / SLA pads Smartaudio / IRC Tramp VTX protocol supported LED controller: Yes Beeper pad: Yes Firmware target: IFLIGHT_BLITZ_ATF435 Mount pattern: 20*20mm/φ4 Dimensions: 30.5*27mm Weight: 5g BEC: 5V 2.5A ESC Specifications: Mounting Holes: 20*20mm/Φ4mm Weight: 11.3g Supports 2-6S lipo input MCU: BB21 Constant: 55 Amps Burst: 65 Amps Telemetry Output: No Current sensor: Yes Current rate: 200 BEC: No Supports: DShot DShot150/300/600/MultiShot/ OneShot etc. Target: Q-H-25 16.7(BlheliS) / Bluejay Q-H-50 (Bluejay) Packing List: 1 x BLITZ Mini ATF435 Flight Controller 1 x BLITZ Mini E55S 4-IN-1 2-6S ESC 1 x Power cables & ESC signal wires Description Our latest BLITZ Stack used in our iFlight BNFs. Ultra fast AT32F435 MCU, powerful 55A for 2-6S batteries. 20x20 mounting pattern. The perfect match for your new frame. Improved circuit design, better components and lower electrical noise! DJI HD VTX Connector (Plug-and-Play / No soldering required), FC indicator LEDs for visual debugging, with LC filter. FC Specifications: MCU: AT32F435RGT7 Gyro: BMI270 Barometer: DPS310 OSD Chip: AT7456E Flash: 16MB (Blackbox flash) UARTS: 6 Motor outputs: 4x (SH1.0 connector) I2C serial: SDA / SLA pads Smartaudio / IRC Tramp VTX protocol supported LED controller: Yes Beeper pad: Yes Firmware target: IFLIGHT_BLITZ_ATF435 Mount pattern: 20*20mm/φ4 Dimensions: 30.5*27mm Weight: 5g BEC: 5V 2.5A ESC Specifications: Mounting Holes: 20*20mm/Φ4mm Weight: 11.3g Supports 2-6S lipo input MCU: BB21 Constant: 55 Amps Burst: 65 Amps Telemetry Output: No Current sensor: Yes Current rate: 200 BEC: No Supports: DShot DShot150/300/600/MultiShot/ OneShot etc. Target: Q-H-25 16.7(BlheliS) / Bluejay Q-H-50 (Bluejay) Packing List: 1 x BLITZ Mini ATF435 Flight Controller 1 x BLITZ Mini E55S 4-IN-1 2-6S ESC 1 x Power cables & ESC signal wires -
About Description Protective lens cover for transport or storage. No more scratches on your lens! All printed with high quality TPU available in various colors. Compatible with:DJI O3 Description Protective lens cover for transport or storage. No more scratches on your lens! All printed with high quality TPU available in various colors. Compatible with:DJI O3 -
About Description Latest Nazgul Frame for Maximum Protection The old days are over, getting your electronics full of dirt and wet grass every time you crash. Our latest frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts. DJI O3 HD Air Unit Low-Latency digital transmission Up to 10 km video transmission range, enjoy a crisp and smooth real-time view in your goggles, even in environments with interference. (Source DJI) 4K Stabilized Video with 155° Ultra-Wide Angle Together with high-grade imaging performance, it delivers exceptional visuals that will keep your audience on the edge of their seats. (Source DJI) Secured Battery Plug with Anti-Spark Filter Plugging in a battery can create a loud spark at the connector which is caused by the high battery current rushing into the low ESR capacitor first as well as filling up ESC capacitance. We’ve added a protective circuit to extend the lifespan of XT60 connectors and prevent rapid voltage or current spikes which can protect your electronics from damage. Specifications: Product Name: Evoque F4 FC: BLITZ Mini F7 Flight Controller ESC: BLITZ Mini E55S 4-IN-1 2-6S 55A ESC Video Transmission: DJI O3 Air Unit Frame wheelbase: 185mm Motor: XING 2205 2450KV motors Prop: HQ 4*3*3 propellers Takeoff Weight: Approx. 330 g (Without battery) Dimensions (L×W×H): 148.5×110×36 mm(Squashed X) / 149*110*36mm (DeadCat) Diagonal Distance: 185 mm Max Speed: 170 Km/h (Manual Mode) Maximum Takeoff Altitude: 7000 m Max Hover Time: Approx. 8 mins Max Flight Distance: 5 km Max Wind Speed Resistance: Level 5 Operating Temperature Range: -10° to 40° C (14° to 104° F) Antennas: DJI O3 Air Unit Dual-Band Antenna GNSS: GPS+SBAS+Galileo+QZSS+Glonass(Optional) Recommended batteries: 6S 1050mAh Battery 6S 1400mAh Battery Video Transmission: Product Name: DJI O3 Air Unit Communication Bandwidth: Max 40 MHz FOV (single screen): 155° Communication Frequency: 2.400-2.4835 GHz (RX only) / 5.725-5.850 GHz (RX and TX) End-to-End Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms. Max Video Transmission Bitrate: 50 Mbps Max Video Transmission Range：10 km (FCC), 2 km (CE), 6 km (SRRC) Operating Temperature Range: -10º to 40º C (14° to 104° F) Power Input: 7.4-26.4 V Audio Transmission: N/A Packing List: 1 x Evoque F4 6S HD BNF 1 x DJI O3 air unit Antenna 1 x Battery pad 4 x HQ 4x3x3 propeller(Pairs) 2 x Battery strap Notice: All iFlight BNFs are tested before shipment to guarantee the highest quality. If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Characteristics Size 4 inch Geometry Squashed X or DeadCat Flight Stack BLITZ Mini F7/E55S Motors 2205 2450KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS Module M10 chipset Max. Speed 170 km/h Weight ca. 330 (without battery) Description Latest Nazgul Frame for Maximum Protection The old days are over, getting your electronics full of dirt and wet grass every time you crash. Our latest frame reduces contamination that could build up on your flight controller or ESCs, preventing failure or short circuits. Strategic airflow to keep your components cool and clean without taking any shortcuts in weight or performance. Illuminated side panels and 360-degree TPU protective parts. DJI O3 HD Air Unit Low-Latency digital transmission Up to 10 km video transmission range, enjoy a crisp and smooth real-time view in your goggles, even in environments with interference. (Source DJI) 4K Stabilized Video with 155° Ultra-Wide Angle Together with high-grade imaging performance, it delivers exceptional visuals that will keep your audience on the edge of their seats. (Source DJI) Secured Battery Plug with Anti-Spark Filter Plugging in a battery can create a loud spark at the connector which is caused by the high battery current rushing into the low ESR capacitor first as well as filling up ESC capacitance. We’ve added a protective circuit to extend the lifespan of XT60 connectors and prevent rapid voltage or current spikes which can protect your electronics from damage. Specifications: Product Name: Evoque F4 FC: BLITZ Mini F7 Flight Controller ESC: BLITZ Mini E55S 4-IN-1 2-6S 55A ESC Video Transmission: DJI O3 Air Unit Frame wheelbase: 185mm Motor: XING 2205 2450KV motors Prop: HQ 4*3*3 propellers Takeoff Weight: Approx. 330 g (Without battery) Dimensions (L×W×H): 148.5×110×36 mm(Squashed X) / 149*110*36mm (DeadCat) Diagonal Distance: 185 mm Max Speed: 170 Km/h (Manual Mode) Maximum Takeoff Altitude: 7000 m Max Hover Time: Approx. 8 mins Max Flight Distance: 5 km Max Wind Speed Resistance: Level 5 Operating Temperature Range: -10° to 40° C (14° to 104° F) Antennas: DJI O3 Air Unit Dual-Band Antenna GNSS: GPS+SBAS+Galileo+QZSS+Glonass(Optional) Recommended batteries: 6S 1050mAh Battery 6S 1400mAh Battery Video Transmission: Product Name: DJI O3 Air Unit Communication Bandwidth: Max 40 MHz FOV (single screen): 155° Communication Frequency: 2.400-2.4835 GHz (RX only) / 5.725-5.850 GHz (RX and TX) End-to-End Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms. Max Video Transmission Bitrate: 50 Mbps Max Video Transmission Range：10 km (FCC), 2 km (CE), 6 km (SRRC) Operating Temperature Range: -10º to 40º C (14° to 104° F) Power Input: 7.4-26.4 V Audio Transmission: N/A Packing List: 1 x Evoque F4 6S HD BNF 1 x DJI O3 air unit Antenna 1 x Battery pad 4 x HQ 4x3x3 propeller(Pairs) 2 x Battery strap Notice: All iFlight BNFs are tested before shipment to guarantee the highest quality. If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Characteristics Size 4 inch Geometry Squashed X or DeadCat Flight Stack BLITZ Mini F7/E55S Motors 2205 2450KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS Module M10 chipset Max. Speed 170 km/h Weight ca. 330 (without battery) -
About Description Stable output power 4 Power levels up to 1600mW; 40 Channels (including Raceband) Fast frequency lock, no startup interference with other pilots Built-in output power self-check functionality VTX telemetry with IRC Tramp protocol Note: VTX is set to 25mW by default! Power levels above 25mW require a HAM license or have to be approved by local authorities! Please ensure you're flying legal frequencies and use our prepared Betaflight VTX tables according to your region. Specifications: Input voltage: 7V～34V Interface: IPEX Power levels: PIT/25mW/400mW/800mW/1600mW Channels: 40 (including Raceband) Mounting pattern: 25.5x25.5mm/Φ1.6 Lightweight: 16.5g (excluding antenna) VTX telemetry: IRC Tramp Betaflight IRC Tramp Configuration: Please download the attached VTX table for Betaflight! RC Tramp VTX table values: 25mW/400mW/800mW/1600mW PDF Instructions: https://drive.google.com/drive/folders/1PangELyOFYp0kknmzMPgHx7xfat-Ggve Packing List: 1 x BLITZ Whoop 1.6W VTX Attention: Please read the instructions for proper wiring before use. It is recommended that before switching on the power, make sure that the antenna has been installed, it can extend the life of the module. It is recommended to ensure the correct voltage range and the correct positive and negative polarity before switching on the power to avoid burning the components. Please keep enough space when you install the VTX to ensure air convection around the module for heat dissipation. Otherwise, the module will enable overheat protection and the power transmission will be reduced or even switched off. Description Stable output power 4 Power levels up to 1600mW; 40 Channels (including Raceband) Fast frequency lock, no startup interference with other pilots Built-in output power self-check functionality VTX telemetry with IRC Tramp protocol Note: VTX is set to 25mW by default! Power levels above 25mW require a HAM license or have to be approved by local authorities! Please ensure you're flying legal frequencies and use our prepared Betaflight VTX tables according to your region. Specifications: Input voltage: 7V～34V Interface: IPEX Power levels: PIT/25mW/400mW/800mW/1600mW Channels: 40 (including Raceband) Mounting pattern: 25.5x25.5mm/Φ1.6 Lightweight: 16.5g (excluding antenna) VTX telemetry: IRC Tramp Betaflight IRC Tramp Configuration: Please download the attached VTX table for Betaflight! RC Tramp VTX table values: 25mW/400mW/800mW/1600mW PDF Instructions: https://drive.google.com/drive/folders/1PangELyOFYp0kknmzMPgHx7xfat-Ggve Packing List: 1 x BLITZ Whoop 1.6W VTX Attention: Please read the instructions for proper wiring before use. It is recommended that before switching on the power, make sure that the antenna has been installed, it can extend the life of the module. It is recommended to ensure the correct voltage range and the correct positive and negative polarity before switching on the power to avoid burning the components. Please keep enough space when you install the VTX to ensure air convection around the module for heat dissipation. Otherwise, the module will enable overheat protection and the power transmission will be reduced or even switched off. -
About Description High quality ELRS (ExpressLRS) or TBS Crossfire compatible antennas from iFlight. Antennas are tuned for 2400Mhz (2.4Ghz) or 868/915Mhz. To get the best signal reception, please mount antennas away from conductive materials like metal, batteries or carbon. Description High quality ELRS (ExpressLRS) or TBS Crossfire compatible antennas from iFlight. Antennas are tuned for 2400Mhz (2.4Ghz) or 868/915Mhz. To get the best signal reception, please mount antennas away from conductive materials like metal, batteries or carbon. -
About Description Highlights: Protected Propellers for indoor and outdoor use, protecting whatever you might bump into from nasty cuts DJI O3 HD Air Unit Low-Latency Digital Transmission with 4K Stabilized Video with 155° Ultra-Wide Angle Universal camera mount and accessories for a wide range of cameras to install Updated BLITZ E80 4-IN-1 ESC for more power and reliability Big size XING2 3110 power motors with extreme lift and flight performance BLITZ M10 GPS module pre-installed (BF GPS rescue or INAV GPS RTH feature available) Camera Power Supply Module // IFlight Camera Power 12V 3A BEC Module Short-circuit Protection Function Specifications: Product Name: ProTek60 Pro O3 FC: BLITZ F7 Pro Flight Controller ESC: BLITZ E80 4-IN-1 Pro ESC Video Transmission: DJI O3 Air Unit Frame: 282mm wheelbase Motor: XING2 3110 1600KV motors Prop: Nazgul 6x4x3 propellers Weight：1466grams Max Speed: 110 Km/H (Manual Mode) Maximum Takeoff Altitude: 3200 m Max Hover Time: Approx. 5.5 mins with 1.3KG load and 6S 4500mAh battery Max Wind Speed Resistance: Level 6 Operating Temperature Range: -10° to 40° C (14° to 104° F) Antennas: Dual Antennas GNSS: GPS + Galileo Video Transmission: Product Name: DJI O3 Air Unit Weight: Approx. 36.4 grams（headband included） Communication Bandwidth: Max 40 MHz FOV (single screen): 155° Communication Frequency: 2.400-2.4835 GHz (RX only) / 5.725-5.850 GHz (RX and TX) End-to-End Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms. Max Video Transmission Bitrate: 50 Mbps Max Video Transmission Range：10 km (FCC), 2 km (CE), 6 km (SRRC) Operating Temperature Range: -10º to 40º C (14° to 104° F) Power Input: 7.4-26.4 V Audio Transmission: N/A Packing List: 1 x ProTek60 Pro O3 BNF 1 x Nazgul 6x4x3 Propellers(Pairs) 2 x Albatross LHCP 5.8GHz SMA FPV Antenna 1 x XT90 Male to XT60 Female Adapter Wire 1 x Fullsend X 6S 5600mAh Battery 2 x Battery Strap 1 x XT90 Smart Smoke Stopper 1 x Prop Wrench Notice: All iFlight BNFs are tested before shipment to guarantee highest quality. If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Characteristics Size 6 inch Geometry Ducted Flight Stack BLITZ F7 Pro/E80 Motors 3110 1600KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS Module M10 chipset Max. Speed 110 km/h Weight ca. 1466 (without battery) Description Highlights: Protected Propellers for indoor and outdoor use, protecting whatever you might bump into from nasty cuts DJI O3 HD Air Unit Low-Latency Digital Transmission with 4K Stabilized Video with 155° Ultra-Wide Angle Universal camera mount and accessories for a wide range of cameras to install Updated BLITZ E80 4-IN-1 ESC for more power and reliability Big size XING2 3110 power motors with extreme lift and flight performance BLITZ M10 GPS module pre-installed (BF GPS rescue or INAV GPS RTH feature available) Camera Power Supply Module // IFlight Camera Power 12V 3A BEC Module Short-circuit Protection Function Specifications: Product Name: ProTek60 Pro O3 FC: BLITZ F7 Pro Flight Controller ESC: BLITZ E80 4-IN-1 Pro ESC Video Transmission: DJI O3 Air Unit Frame: 282mm wheelbase Motor: XING2 3110 1600KV motors Prop: Nazgul 6x4x3 propellers Weight：1466grams Max Speed: 110 Km/H (Manual Mode) Maximum Takeoff Altitude: 3200 m Max Hover Time: Approx. 5.5 mins with 1.3KG load and 6S 4500mAh battery Max Wind Speed Resistance: Level 6 Operating Temperature Range: -10° to 40° C (14° to 104° F) Antennas: Dual Antennas GNSS: GPS + Galileo Video Transmission: Product Name: DJI O3 Air Unit Weight: Approx. 36.4 grams（headband included） Communication Bandwidth: Max 40 MHz FOV (single screen): 155° Communication Frequency: 2.400-2.4835 GHz (RX only) / 5.725-5.850 GHz (RX and TX) End-to-End Latency With DJI FPV Goggles V2: 810p/120fps Video Transmission Quality: The latency is lower than 28 ms. 810p/60fps Video Transmission Quality: The latency is lower than 40 ms. With DJI Goggles 2: 1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms. Max Video Transmission Bitrate: 50 Mbps Max Video Transmission Range：10 km (FCC), 2 km (CE), 6 km (SRRC) Operating Temperature Range: -10º to 40º C (14° to 104° F) Power Input: 7.4-26.4 V Audio Transmission: N/A Packing List: 1 x ProTek60 Pro O3 BNF 1 x Nazgul 6x4x3 Propellers(Pairs) 2 x Albatross LHCP 5.8GHz SMA FPV Antenna 1 x XT90 Male to XT60 Female Adapter Wire 1 x Fullsend X 6S 5600mAh Battery 2 x Battery Strap 1 x XT90 Smart Smoke Stopper 1 x Prop Wrench Notice: All iFlight BNFs are tested before shipment to guarantee highest quality. If you still encounter a problem after receiving your shipment, please immediately contact our iFlight customer support at www.iflightrc.freshdesk.com. Characteristics Size 6 inch Geometry Ducted Flight Stack BLITZ F7 Pro/E80 Motors 3110 1600KV Video Transmitter DJI O3 Air Unit Radio Transmitter DJI FPV RC2, ELRS, TBS (optional) GPS Module M10 chipset Max. Speed 110 km/h Weight ca. 1466 (without battery) -
About Description The Fullsend Li-Po batteries offer the best bang for your buck! These batteries have an awesome performance with 95C discharge capability and cost a fraction of most other batteries on the market. High-quality cells ensure even delivery of power with minimal voltage sag under heavy loads. Each Fullsend battery is individually QC checked at the factory, ensuring you get the best performing battery out of the box. The Fullsend battery design features an all black shrink cover, black XT60 connector and black balance connector for a sleek stealth look. Guaranteed to look good on any aircraft. Specifications: Capacity: 3300mAh Cell Combination: 6S1P Discharge rate: 95C Weight: 442g Size: 37*44*141mm Battery type: LI-PO Connector: XT60 Recommended for: Chimera7 Pro V2 Chimera7 Pro BOB57 O3 Nazgul Evoque F6 O3 Packing List: 1x Fullsend 6S 3300mAh 95C Battery Description The Fullsend Li-Po batteries offer the best bang for your buck! These batteries have an awesome performance with 95C discharge capability and cost a fraction of most other batteries on the market. High-quality cells ensure even delivery of power with minimal voltage sag under heavy loads. Each Fullsend battery is individually QC checked at the factory, ensuring you get the best performing battery out of the box. The Fullsend battery design features an all black shrink cover, black XT60 connector and black balance connector for a sleek stealth look. Guaranteed to look good on any aircraft. Specifications: Capacity: 3300mAh Cell Combination: 6S1P Discharge rate: 95C Weight: 442g Size: 37*44*141mm Battery type: LI-PO Connector: XT60 Recommended for: Chimera7 Pro V2 Chimera7 Pro BOB57 O3 Nazgul Evoque F6 O3 Packing List: 1x Fullsend 6S 3300mAh 95C Battery -
About Description HQ propeller quality for your 6 inch FPV drone. Default Propeller for the iFlight Nazgul F6X and F6D. Description HQ propeller quality for your 6 inch FPV drone. Default Propeller for the iFlight Nazgul F6X and F6D. -
About Description XING-E series are very strong and powerful FPV motors for FPV racing, great value choice with well known XING performance focuses on quality, the XING-E series affordable motors that are strong and durable. This 2207 sized motor features a High-strength 4mm steel hollow shaft, Single strand windings for performance, M3 shaft screw, and larger 9x4x4mm NSK bearings. Features: High-strength 5mm Steel shaft N52H High-temperature magnets, NSK bearings 16x16mm hole pattern Single strand copper winding Hex bolt shaft set screw Specifications: Model: XING-E Pro 2207 Motor KV: 1800KV / 2450KV / 2750KV Weight(included wire): 33.8g Dimension: φ28.5*19.7mm Interphase Resistance:81.5mΩ / 46.8mΩ / 41mΩ Peak Current: 35.22A / 42.63A / 50.03A Max Watt: 845.3W / 682.1W / 800.5W Shaft Diameter: 22mm Shaft Protruding Length: 7mm Configuration: 12N14P Mounting Holes: 16*16 φ3mm Packing List: 1 x XING-E Pro 2207 motor Description XING-E series are very strong and powerful FPV motors for FPV racing, great value choice with well known XING performance focuses on quality, the XING-E series affordable motors that are strong and durable. This 2207 sized motor features a High-strength 4mm steel hollow shaft, Single strand windings for performance, M3 shaft screw, and larger 9x4x4mm NSK bearings. Features: High-strength 5mm Steel shaft N52H High-temperature magnets, NSK bearings 16x16mm hole pattern Single strand copper winding Hex bolt shaft set screw Specifications: Model: XING-E Pro 2207 Motor KV: 1800KV / 2450KV / 2750KV Weight(included wire): 33.8g Dimension: φ28.5*19.7mm Interphase Resistance:81.5mΩ / 46.8mΩ / 41mΩ Peak Current: 35.22A / 42.63A / 50.03A Max Watt: 845.3W / 682.1W / 800.5W Shaft Diameter: 22mm Shaft Protruding Length: 7mm Configuration: 12N14P Mounting Holes: 16*16 φ3mm Packing List: 1 x XING-E Pro 2207 motor -
About Description Quality Gemfan Propeller for your 5 inch FPV drone. Default Propeller for the iFlight Nazgul F5 V1 and V2. Propellers designed especially for competition flying, to which MCK lent its name. The 51366 MCK ReV3 propellers are the next iteration of the popular propellers.Compared to the previous version, the V3 has a reduced pitch from 3.6" to 2.8". This makes the propeller particularly suitable for high Kv motors(2207 1950-2100Kv, 6S). Features Diameter: 5" Pitch: 2.8" Number of blades: 3 Weight: 4.2g Recommended motor: 2207/2306 Packing List per Bag 2x CW GEMFAN Hurricane MCK Rev3 51366 2x CCW GEMFAN Hurricane MCK Rev3 51366 Description Quality Gemfan Propeller for your 5 inch FPV drone. Default Propeller for the iFlight Nazgul F5 V1 and V2. Propellers designed especially for competition flying, to which MCK lent its name. The 51366 MCK ReV3 propellers are the next iteration of the popular propellers.Compared to the previous version, the V3 has a reduced pitch from 3.6" to 2.8". This makes the propeller particularly suitable for high Kv motors(2207 1950-2100Kv, 6S). Features Diameter: 5" Pitch: 2.8" Number of blades: 3 Weight: 4.2g Recommended motor: 2207/2306 Packing List per Bag 2x CW GEMFAN Hurricane MCK Rev3 51366 2x CCW GEMFAN Hurricane MCK Rev3 51366 -
About Description For Nazgul Evoque V2 series compatible with F5D, F5X, F6D or F6X. Including LED strips, connector wires and XT60 back cover. Description For Nazgul Evoque V2 series compatible with F5D, F5X, F6D or F6X. Including LED strips, connector wires and XT60 back cover.
